To connect a distribution box to a switch box, run phase, neutral, and earth wires from the DB's output MCBs to the corresponding terminals in the switch box, ensuring proper protection and labeling.

Step-by-Step Connection

1. Identify the Main and Branch Circuits

• The distribution box (DB) contains the main MCB or main switch, branch MCBs, and protective devices like RCCBs for safety .
• Each switch box in a room receives power from a specific branch MCB in the DB . 2. Prepare the Wiring
• Use appropriate wire sizes based on the load (e.g., 1.5 mm² for lighting, 2.5 mm² for sockets).
• Label wires for phase (live), neutral, and earth to avoid confusion .
• Ensure wires are bound neatly with plastic ties and routed without sharp bends . 3. Connect the DB to the Switch Box
• From the output terminals of the branch MCB in the DB, run the phase wire to the live terminal of the switch box.
• Connect the neutral wire from the DB's neutral bus to the neutral terminal in the switch box.
• Connect the earth wire from the DB's earth bus to the earth terminal in the switch box .
• Maintain consistent wiring direction: typically, left side for incoming wires and right side for outgoing wires . 4. Safety and Testing
• After connections, check all terminals are tight and no bare wires are exposed.
• Perform a safety inspection to ensure there are no short circuits or overloads .
• Switch on the main MCB and test each switch and socket for proper operation . 5. Optional Tips
• Use double-pole MCBs for high-power appliances and single-pole MCBs for lighting circuits .
• Clearly mark the circuits in the DB for easier maintenance.
• If unsure, consult a licensed electrician to comply with local electrical codes. By following these steps, you can safely and efficiently connect a distribution box to a switch box, ensuring proper protection and reliable power distribution throughout your home.
