Article Overview
Optical switches can range from 16 ports in compact campus models to over 500 ports in high-density data center platforms.
High-Density Optical Switches
- Molex High-Radix OCS Platform supports up to 544x544 ports, with a roadmap to exceed 1,000 ports, enabling large-scale GPU clusters and high-bandwidth fabrics with fewer switch tiers .
- POLATIS Series 7000 offers a 384x384 port configuration, designed for low-latency, high-performance all-optical routing in data centers and telecom applications .
Medium and Campus Optical Switches
- Smaller all-optical switches, such as the Ruijie RG-SF2920-16GT2SFP-P, provide 16 ports (10/100/1000BASE-T) with additional SFP uplink ports, suitable for indoor or campus deployments .
Port Numbering and Configuration
- Optical switches often use modular designs with slots, subcards, and port sequence numbers to identify physical ports. Ports can be split or aggregated depending on the module type (e.g., SFP, CSFP), allowing flexible configurations .
- All-optical switches typically support high-speed interfaces such as 10G, 25G, 40G, 100G, and higher, depending on the model and deployment scenario .
Summary
The number of ports on an optical switch varies widely based on the intended application:
- High-performance data centers: hundreds to over a thousand ports (Molex, Polatis)
- Enterprise or campus networks: tens of ports (16–48 ports)
- Port flexibility: modular designs allow splitting, aggregation, and support for multiple speeds This range ensures that optical switches can meet the needs of both large-scale, high-bandwidth environments and smaller, localized network deployments.
