Article Overview
A CXP optical module is a hot-swappable 100G transceiver with 12 parallel 10Gbps channels, designed for high-density, short-reach optical networking in data centers and HPC environments.
Definition and Meaning
CXP stands for Compact 100G Pluggable. The "C" represents 12 in hexadecimal, "X" indicates a 10Gbps transfer rate per channel, and "P" refers to a hot-swappable pluggable module . It is slightly larger than a QSFP28 module but smaller than a CFP2 module, making it suitable for high-density cabling and rack-to-rack interconnections .
How It Works
CXP modules use parallel optics technology to achieve high-speed data transmission :
- Electrical input: 12 × 10Gbps signals enter via an 84-pin connector.
- Optical conversion: Signals are converted into 12 optical channels using 850nm VCSEL (Vertical-Cavity Surface-Emitting Laser) arrays.
- Transmission: Optical signals travel through 24-core multimode MPO/MTP fiber cables.
- Reception: A PIN photodiode array converts the optical signals back into electrical signals at the receiving end. This design allows low-latency, high-throughput interconnections, ideal for short-reach applications such as data center networking and high-performance computing .
Technical Specifications
- Maximum data rate: 120Gbps (12 channels × 10Gbps each)
- Fiber type: Multimode (OM3 up to 100m, OM4 up to 150m)
- Interface: MPO/MTP connectors for optical cables
- Power consumption: Up to 3.5W
- Operating temperature: 0°C to 70°C
- Hot-swappable: Yes, allowing easy replacement without shutting down equipment
Applications
CXP modules are primarily used in:
- Data centers for short-distance, high-density interconnects
- High-performance computing (HPC) networks
- Enterprise core aggregation and service provider transport
- Breakout connectivity to 10G SFP+ or 40G QSFP+ modules using appropriate fiber patch cables
Compatibility Notes
CXP modules cannot directly connect to QSFP-SR4 modules due to lane differences (CXP uses 12 lanes, QSFP uses 4 lanes). Breakout connections require matching wavelength transceivers, typically 850nm SFP+ . In summary, the CXP optical module is a high-speed, compact, and versatile transceiver designed to meet the growing demands of short-reach, high-density optical networking in modern data centers and HPC environments.
