A low-voltage circuit breaker jumper is a conductive link used to distribute power across multiple breakers or terminals without running separate wires to each one.

Purpose of a Jumper

In a low-voltage distribution box, a jumper serves to electrically connect multiple circuit breakers or terminal blocks, allowing a single input power source to feed several circuits simultaneously. This reduces wiring complexity, saves space, and ensures consistent voltage across connected devices . Jumpers are particularly useful in industrial control panels or switchgear where multiple breakers need to share a common power bus.

Types and Installation

Jumpers can be pre-manufactured metal bars, plug-in bridges, or modular terminal block jumpers. They are designed to fit specific breaker types or terminal blocks, so selecting the correct size and type is critical . Installation typically involves:

• Aligning the jumper with the designated terminals on the breakers or terminal blocks.
• Inserting or clipping the jumper securely to ensure proper electrical contact.
• Trimming excess length if the jumper spans fewer terminals than its full size.
• Ensuring compatibility with the breaker's voltage and current ratings to prevent overheating or failure . Some jumpers are insulated for safety, while others are bare metal for direct bus connections. In low-voltage switchgear, jumpers are often used in draw-out or through-the-door breakers, allowing power distribution without opening the panel .

Practical Considerations

• Current Rating: Ensure the jumper can handle the total current of all connected breakers.
• Safety: Use insulated jumpers where accidental contact is possible.
• Standards Compliance: Follow IEC or IEEE standards for low-voltage switchgear and distribution panels .
• Flexibility: Modular jumpers can be cut or modified to fit the exact number of terminals needed, reducing clutter and improving panel organization .

Summary

A low-voltage circuit breaker jumper is an essential component for efficient power distribution in a distribution box. It simplifies wiring, ensures reliable connectivity, and allows multiple breakers to share a single power source safely. Proper selection, installation, and adherence to safety standards are key to effective use .
