Article Overview
An access switch can connect to another Layer 2 switch to extend VLANs, provide additional ports, and maintain Layer 2 adjacency for end devices.
Role of Access Switches
An access switch is a network edge device that connects end-user devices such as PCs, IP phones, wireless access points, cameras, and IoT devices to the broader network. It typically provides high port density, Power over Ethernet (PoE), and forwards traffic upstream to distribution or core layers . Access switches operate primarily at Layer 2, forwarding frames based on MAC addresses within the same VLAN .
Layer 2 Connectivity Between Switches
When an access switch connects to another Layer 2 switch, the connection can be configured as either an access port or a trunk port:
- Access Port: Carries traffic for a single VLAN. This is suitable when the connected switch is extending the same VLAN to additional devices.
- Trunk Port: Carries traffic for multiple VLANs, allowing VLANs to span across multiple switches. This is essential for maintaining consistent VLAN segmentation across the network . The Layer 2 connection ensures that MAC address tables are dynamically learned and maintained, allowing frames to be forwarded efficiently between switches without routing . If a frame's destination MAC address is unknown, it is flooded to all ports within the VLAN, ensuring connectivity for new devices.
Benefits of Connecting Access Switches to Layer 2 Switches
- VLAN Extension: VLANs can be extended across multiple switches, allowing devices on different access switches to communicate within the same broadcast domain .
- Port Expansion: Connecting multiple Layer 2 switches increases the number of available ports for end devices without requiring Layer 3 routing.
- Layer 2 Adjacency: Certain applications, such as NIC teaming, high-availability clusters, and database clusters, require devices to be in the same Layer 2 domain. Connecting access switches at Layer 2 preserves this adjacency .
- Simplified Management: Layer 2 connections reduce the need for IP routing at the access layer, simplifying configuration and minimizing latency .
Considerations
- Spanning Tree Protocol (STP): To prevent loops in Layer 2 topologies, STP or Rapid STP should be enabled.
- Broadcast Domains: All devices in the same VLAN share the broadcast domain, so careful VLAN planning is necessary to avoid excessive broadcast traffic.
- Trunk Configuration: When multiple VLANs are required, trunk ports must be properly configured to carry all necessary VLANs between switches. In summary, connecting an access switch to another Layer 2 switch is a common practice in enterprise and data center networks. It allows VLAN extension, port expansion, and maintains Layer 2 adjacency for end devices, while relying on MAC-based forwarding and optional trunking to manage multiple VLANs efficiently .
