Cutting holes in cable trays requires proper measurement, marking, the right tools, and safety precautions to ensure clean, precise openings without compromising tray integrity.

Tools and Equipment

To cut holes in metal or stainless steel cable trays, you will need:

• Measuring tape and marker or pencil for accurate layout
• Clamps or a vice to secure the tray
• Hacksaw, metal-cutting power saw, or specialized cable tray cutter
• Drill with high-quality metal drill bits (for round holes)
• Cutting fluid or lubricant (especially for stainless steel)
• File, sandpaper, or deburring tool to smooth edges
• Safety gear: gloves, safety goggles, dust mask, and hearing protection

Step-by-Step Process

1. Planning and Marking

• Measure the location and size of the hole required.
• Mark the cut line clearly on the tray using a permanent marker or chalk.
• For angled or offset cuts, use formulas to calculate the cut-out size based on tray width and desired angle or offset distance .

2. Securing the Tray

• Clamp the tray firmly in a vice or on a stable work surface to prevent movement during cutting.
• Ensure the tray is level and supported to avoid bending or warping.

3. Cutting the Hole

• For rectangular or custom-shaped holes, use a hacksaw or power saw along the marked lines.
• For circular holes, drill a pilot hole first, then enlarge using a hole saw or step drill bit.
• Apply cutting fluid to reduce heat and friction, especially for stainless steel trays .
• Maintain steady pressure and a consistent cutting speed to avoid jagged edges.

4. Finishing

• Remove burrs and sharp edges using a file, deburring tool, or sandpaper.
• Clean the cut area to remove metal shavings and debris.
• Inspect the hole to ensure it meets the required dimensions and is smooth for cable installation .

Tips for Efficiency and Safety

• Use specialized battery-powered cable tray cutters for faster and cleaner cuts in professional settings.
• Always wear appropriate personal protective equipment to prevent injury from metal shards or dust.
• Plan cuts carefully to maintain the structural integrity of the tray and avoid weakening side rails or supports .
• When making multiple angled or offset cuts, measure and test the first cut before proceeding with additional cuts . By following these steps, you can safely and accurately cut holes in cable trays for conduit, cable pass-throughs, or custom installations while maintaining the tray's strength and compliance with electrical standards.
